24W 36V Bridgelux chip inside 3 step RA70 RA80 RA90

• Available in 3-step, 2-step and 1.5-step EasyWhite® bins
• Available in 70, 80, 90, 95 and 97 minimum Ra options
• Low thermal resistance
• RoHS and REACh compliant

The TYF COB package has high efficacy, high Ra, low power consumption, wide viewing angle and a compact form factor. These features make the package an ideal LED for lighting applications.

• Indoor General Lighting: Spotlights, Track Lights, Downlights
• Industrial lighting: Floodlight, High bay light, Streetlight

• Power: Standard power 23W / Max power 30W
• Forward Voltage: 34-38V
• Forward Current: Standard current 640mA / Max current 800mA
• Operating Temperature: -40°C to +85°C
• Junction Temperature: 125°C
• Storage Temperature: -40°C to +105°C
• ESD Sensitivity: 2000V
• Reverse Voltage: Reverse testing is not allowed
• Reverse Current: 5μA
• Soldering Temperature: 350°C/3-5sec
